Fully Automatic Rigid Box Making Machine KY-6003 / KY-6005 — Layout-Forming Integrated Box Former with Robotic Precision
Produce premium top-and-bottom lid rigid boxes in one machine — no corner-staying, no panel-splicing equipment needed. Yamaha robotic arm positions greyboard with sub-millimeter accuracy while simultaneous cold and hot glue creates structurally perfect boxes at 15-28 pcs/min.
Eliminate 3 Machines From Your Rigid Box Production Line
Traditional rigid box making requires separate forming, corner staying, and panel splicing machines. The KY-6003/6005 does it all in one integrated unit.
Traditional Multi-Machine Workflow
- Separate box forming, corner staying, and panel splicing machines
- 3-5 operators needed across different stations
- Large floor space for multiple machines and WIP inventory
- Material waste from extra corner tapes and splicing strips
- Quality inconsistency between stations and shifts
- Slow changeover — each machine needs individual setup
KY-6003/6005 Integrated Solution
- One machine replaces box former + corner stayer + panel splicer
- Minimal operators for fully automatic production
- Single machine footprint — 70% less floor space needed
- Zero corner tape waste — dual glue system bonds directly
- Yamaha robotic arm ensures identical quality on every box
- Quick changeover with stored recipes for repeat jobs
Revolutionary Rigid Box Technology
The KY-6003/6005 represents a new generation of integrated box forming — combining precision robotics, dual adhesive systems, and one-machine-does-all simplicity.
No Corner Staying Required
The integrated layout-forming process produces structurally rigid corners during box forming itself. No separate corner-staying machine, no corner tapes — fewer steps, less waste, lower cost per box.
Yamaha Robotic Arm
Industrial-grade Yamaha robotic arm delivers sub-millimeter precision positioning of greyboard panels. Repeatable accuracy ensures perfect alignment on every box at full production speed.
3-Board & 5-Board Splicing
Handle both 3-piece (base + 2 walls) and 5-piece (base + 4 walls) greyboard constructions seamlessly. Top-and-bottom lid boxes formed completely without separate splicing equipment.
Dual Adhesive System
Cold glue and hot melt glue applied simultaneously in one cycle. Cold glue provides long-term structural bonding while hot glue delivers instant tack — speed and durability in one pass.
15-28 Boxes Per Minute
High-speed production with consistent output regardless of shift or operator. Fully automatic feeding and forming eliminates the throughput bottlenecks of multi-machine workflows.
Wide Material Range
Greyboard from 1mm to 8mm, tissue/wrapping paper from 80 to 350 g/m². Handles everything from lightweight gift boxes to heavy-duty luxury packaging and presentation cases.
KY-6003 / KY-6005 Specifications
| Parameter | KY-6003 | KY-6005 |
|---|---|---|
| Max Tissue Paper Size | 620 × 800 mm | 620 × 800 mm |
| Min Tissue Paper Size | 50 × 120 mm | 50 × 120 mm |
| Max Box Size (L×W×H) | 500 × 400 × 120 mm | 500 × 400 × 180 mm |
| Min Box Size (L×W×H) | 150 × 80 × 20 mm | 150 × 80 × 20 mm |
| Tissue Paper Thickness | 80 – 350 g/m² | 80 – 350 g/m² |
| Greyboard Thickness | 1 – 8 mm | 1 – 8 mm |
| Production Speed | 15 – 28 pcs/min | 15 – 28 pcs/min |
| Motor Power | 8 KW / 380V 3-Phase | 8 KW / 380V 3-Phase |
| Machine Weight | 6,500 kg | 6,500 kg |
| Machine Dimensions | 2,900 × 8,600 × 3,300 mm | |
KY-6003 vs KY-6005 — Which Model?
Both models share identical speed, material range, power requirements, and build quality. The only difference is maximum box height: the KY-6003 handles boxes up to 120mm tall, while the KY-6005 extends to 180mm.
Choose the KY-6005 if you produce tall boxes for cosmetics, electronics, or premium gifts. Choose the KY-6003 if your products are standard-height boxes and you want to optimize for the most common sizes.
Infrastructure Requirements
- 380V 3-phase industrial power supply (8 KW)
- Compressed air: 7.5 KW compressor, 7-9 kg pressure
- Floor space: minimum 3m × 9m with clearance
- Floor load capacity: 6,500 kg machine weight
- Adequate ventilation for adhesive fumes
- On-site installation and training by Kylin engineers
Rigid Box Making Machine Demo
Watch the complete box-forming cycle — from flat greyboard and tissue paper to finished rigid boxes, with no corner staying required.
From Flat Materials to Finished Rigid Box in 4 Steps
A fully automated cycle — load materials, and the machine handles everything from gluing to finished box output.
Auto Material Feed
Load greyboard panels and tissue (wrapping) paper into the feeder trays. The machine automatically feeds both materials into the forming station.
Robotic Positioning
Yamaha robotic arm picks and positions each greyboard panel with sub-millimeter accuracy. 3-board or 5-board layout is assembled on the forming bed.
Dual Glue & Form
Cold glue and hot melt are applied simultaneously. The tissue paper wraps the greyboard layout, walls fold up, and corners bond structurally — no corner staying needed.
Finished Box Output
The completed rigid box exits the machine ready for quality inspection and packing. Top and bottom lids produced in the same workflow.
Premium Packaging for Every Industry
The KY-6003/6005 produces top-and-bottom lid rigid boxes used across luxury, consumer electronics, cosmetics, and specialty packaging markets.
Luxury Gift Boxes
Premium gift packaging for holidays, corporate events, and luxury retail with fabric or foil-wrapped finishes.
Jewelry & Watch Boxes
Rigid presentation cases for rings, necklaces, bracelets, and luxury watches with precise wall alignment.
Electronics Packaging
Smartphone, tablet, and premium electronics unboxing experiences that match brand quality expectations.
Cosmetics & Perfume
Luxury cosmetics packaging, perfume boxes, and beauty product sets with flawless matte or gloss finishes.
Wine & Spirits
Premium bottle packaging, spirit gift sets, and wine box collections with thick greyboard for maximum protection.
Fashion & Apparel
Shirt boxes, shoe boxes, accessories packaging, and luxury fashion brand boxes with custom tissue wrapping.
Machine & Sample Boxes
KY-6003/6005 Integrated vs. Traditional Multi-Machine Workflow
See how consolidating your rigid box production into one machine transforms your economics.
| Factor | KY-6003/6005 Integrated | Traditional (3+ Machines) |
|---|---|---|
| Machines Required | 1 integrated unit | Box former + corner stayer + panel splicer |
| Corner Staying | Not needed — built into forming process | Separate machine + corner tape material |
| Production Speed | 15-28 pcs/min (continuous) | Limited by slowest machine in chain |
| Operators Required | Minimal — fully automatic feeding | 3-5 operators across stations |
| Floor Space | Single footprint: 2.9m × 8.6m | 3+ machine footprints + WIP staging area |
| Material Waste | Zero corner tape waste — dual glue direct bond | Corner tapes, splicing strips, adhesive waste |
| Quality Consistency | Yamaha robotic arm — identical every time | Varies between operators and handoffs |
| Changeover Time | Quick recipe recall for repeat jobs | Each machine adjusted separately |
What Our Customers Say
Join 10,000+ packaging professionals in 30 countries who trust Kylin Machines for premium rigid box production.
“The machine is working now fine, beautiful… thank you so much and maybe if we need other kind of box making machines I will contact you.”
Nadine Kodsy
CEO — Bassil Bookbinding
“Your box corner taper has been running like a champion saving us time and money!! As we continue to grow we will definitely keep in touch.”
Jason Hopkins
Print & Marketing — Ampersand
“I am writing to thank you for the recent delivery of spare parts. We received the shipment in good condition and are pleased with the quality of the products.”
Boris Boguslavskiy
CEO — Taropack
Rigid Box Making Machine FAQ
Common questions about the KY-6003/6005 fully automatic rigid box making machine and integrated box forming technology.
Traditional rigid box production requires a separate corner-staying machine to tape or glue the folded corners of greyboard boxes for structural integrity. The KY-6003/6005 eliminates this step entirely — the integrated layout-forming process with simultaneous cold and hot glue produces structurally rigid corners directly during box forming, saving an entire machine and labor step from the production line.
3-board splicing constructs boxes from three greyboard pieces (base + two side walls), while 5-board splicing uses five pieces (base + four separate side walls). The KY-6003/6005 handles both constructions in one machine, forming complete top-and-bottom lid boxes without needing separate panel-splicing equipment. This flexibility lets you produce different box styles on the same line.
The KY-6003/6005 produces 15 to 28 rigid boxes per minute depending on box size and greyboard thickness. Smaller, thinner boxes run at the upper end of the range, while larger, thicker constructions run slightly slower. This is significantly faster than traditional multi-machine workflows where throughput is bottlenecked by the slowest station.
The only difference is maximum box height: KY-6003 handles boxes up to 120mm tall, while KY-6005 extends to 180mm tall. All other specifications — speed, material range, power, dimensions, and weight — are identical. Choose the KY-6005 if you produce tall packaging for cosmetics, electronics, wine boxes, or other deep-box applications.
Both simultaneously. The KY-6003/6005 applies cold glue and hot melt glue in the same forming cycle. Cold glue provides long-term structural bonding that cures to full strength over hours, while hot glue provides instant tack so boxes can be handled immediately after forming. This dual-adhesive system delivers both production speed and bond durability.
You need: 380V 3-phase industrial power (8 KW), a 7.5 KW air compressor (7-9 kg pressure), a minimum floor space of 3m × 9m with clearance for loading and maintenance, and adequate floor load capacity for the 6,500 kg machine. Kylin engineers provide on-site installation, calibration, and operator training.
The KY-6003/6005 is fully automatic with auto-feeding of both greyboard and tissue paper. Minimal operators are needed — typically one person to load materials and monitor output, compared to 3-5 operators required for a traditional multi-machine rigid box production line.
Kylin Machines provides a 3-year quality warranty, on-site engineer installation and training, free remote technical support, priority spare parts delivery, and scheduled maintenance programs. With 10,000+ customers in 30 countries, Kylin also offers regional service networks for faster on-site response when needed.
Ready to Consolidate Your Rigid Box Production?
Get a free quote for the KY-6003/6005 fully automatic rigid box making machine. Factory-direct pricing, Yamaha robotic precision, and on-site installation included.
The Future of Rigid Box Manufacturing: Integrated Layout-Forming Technology
Rigid boxes — also known as set-up boxes — are the gold standard of premium packaging. From luxury cosmetics and high-end electronics to jewelry, spirits, and corporate gifts, a well-made rigid box communicates quality before the customer even opens it. But traditionally, producing rigid boxes required a complex multi-machine workflow: separate equipment for greyboard forming, corner staying, panel splicing, and tissue wrapping — each needing its own operator, floor space, and maintenance schedule.
The KY-6003/6005 fully automatic rigid box making machine by Kylin Machines represents a paradigm shift in rigid box manufacturing. By integrating layout forming, 3-board and 5-board splicing, simultaneous cold and hot glue application, and tissue wrapping into a single automated machine with a Yamaha robotic arm, it eliminates the need for separate corner-staying and panel-splicing equipment entirely.
This integrated approach delivers measurable advantages: fewer machines on the floor (one instead of three or more), fewer operators (fully automatic feeding vs. 3-5 station workers), zero corner tape waste (the dual adhesive system bonds corners directly during forming), and consistent quality from the Yamaha robotic arm’s sub-millimeter positioning accuracy on every single box.
At 15-28 boxes per minute with greyboard up to 8mm thick and tissue paper from 80 to 350 g/m², the KY-6003/6005 covers the full spectrum of rigid box applications — from thin gift boxes to heavy-duty luxury packaging. Kylin Machines supports every installation with a 3-year warranty, on-site engineer training, and a global service network serving 10,000+ customers across 30 countries.
