Fully Automatic Twin Wire Binder
The Fully Automatic Twin-Wire Binder is a high-performance industrial binding solution designed for large-scale production of calendars, notebooks, and documents. With speeds up to 2000 books per hour and support for both 2:1 and 3:1 wire pitch, this machine delivers exceptional efficiency and precision for professional binding operations.
Technical Specifications
| Punching Thickness | 1 – 6 mm (single-pass) |
|---|---|
| Punching Depth | 13 mm |
| Max Punching Stages | Up to 5 per book |
| Wire Pitch | 2:1 and 3:1 |
| Binding Wire Size | 1/4″ – 7/8″ |
| Double-Wire Feeding | Auto cutting, threading & pressing |
| Max Sheet Width | 510 – 800 mm |
| Min Sheet Width | 100 – 140 mm |
| Working Speed | 800 – 2000 books/hour |
| Air Compressor Power | 3 kW |
| Dimensions (W×D×H) | 4800 × 2600 × 1600 mm |
| Machine Weight | 1250 – 1500 kg |
Key Features
Industry-leading production speed of 800-2000 books per hour ensures maximum output for high-volume binding operations.
Complete automation from punching to wire feeding, cutting, threading, and pressing for hands-free operation.
Compatible with both 2:1 and 3:1 wire pitch configurations, accommodating various binding requirements.
Up to 5 punching stages per book with 1-6mm single-pass thickness capacity for heavy-duty applications.
Handles sheet widths from 100mm to 800mm, suitable for everything from small notebooks to large calendars.
Advanced PLC control with touchscreen interface for easy operation, parameter adjustment, and diagnostics.
Discover how our fully automatic twin-wire binder can revolutionize your production line with speeds up to 2000 books per hour
Product Description
The Fully Automatic Twin-Wire Binder is an industrial-grade binding solution engineered for high-volume production environments. This advanced machine integrates punching, wire feeding, cutting, threading, and pressing into a single automated workflow, dramatically reducing labor costs while increasing output quality and consistency.
“Upgrading to automated double-loop wire binding reduces labor overhead and guarantees uniform O-wire closure on every single notebook and calendar.”
With its robust 1250-1500kg construction and compact 4800×2600×1600mm footprint, this machine is built for continuous operation in demanding print shop and bindery environments. The dual wire pitch support (2:1 and 3:1) provides flexibility for various binding applications.
- Ultra-high-speed binding at 800-2000 books per hour
- Automatic wire cutting, threading, and forming in one seamless process
- Up to 5 punching stages with 1-6mm single-pass capacity
- Wire sizes from 1/4″ to 7/8″ for various document thicknesses
- Sheet width range 100-800mm for diverse product sizes
Application Examples
The Fully Automatic Twin-Wire Binder is ideal for producing calendars, notebooks, planners, catalogs, and various bound documents. The high-speed operation and consistent quality make it perfect for commercial print shops, binderies, and in-house print facilities requiring professional-grade binding.
